Brake / lockML Series
Double Spring-Loaded PU Caster
Cast iron red PU double spring loaded caster with double ball bearing.
Red PU on cast ironDouble ball bearingHeavy-duty casters
Type
Wheel size (mm)
- Load / caster
- 350 kg
- Overall height
- 225 mm
- Wheel
- 150
Message: “Hi Star Brand, I'm interested in Double Spring-Loaded PU Caster, 150 mm. Please share price and availability.”
- Warranty and test certificate given
- PU insertion double spring
- Bulk and dealer orders welcome
- We reply the same working day.
DWG · Double Spring-Loaded PU Caster · not to scale
Technical drawing
Key dimensions for the selected size. Full figures are in the table below.
Specifications
As printed in the Star Brand catalogue, page 7. Tap a row to select that size.
| Wheel dia (mm) | Wheel width (mm) | Height (mm) | Swivel plate (mm) | Swivel hole centre (mm) | Fixed plate (mm) | Fixed hole centre (mm) | Offset (mm) | Plate thickness (mm) | Wheel block (mm) | Load (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
| 125 | 48 | 190 | 138 x 108 | 105 x 80 | 138x108 | 105 x 80 | 48 | 5.5 | 6 | 350 |
| 150 | 48 | 225 | 138 x 108 | 105 x 80 | 138x108 | 105 x 80 | 58 | 5.5 | 6 | 350 |
