22075 TPR · Swivel / Fixed / Brake
Chrome TPR Caster
Light & furniture casters75–125 mm · up to 100 kg
Brake / lockFY / ML Series · 22100NP
PVC, PP & Grey TPR Caster
PVC / PP / grey TPR caster double ball bearing.
PVC / PP / grey TPRDouble ball bearingLight & furniture casters
Type
Wheel size (mm)
- Load / caster
- 80 kg
- Overall height
- 130 mm
- Wheel
- 100x32
Message: “Hi Star Brand, I'm interested in 22100NP, 100x32 mm. Please share price and availability.”
- Bulk and dealer orders welcome
- We reply the same working day.
DWG · 22100NP · not to scale
Technical drawing
Key dimensions for the selected size. Full figures are in the table below.
Specifications
As printed in the Star Brand catalogue, page 12. Tap a row to select that size.
| Swivel code | Fixed code | Brake code | Height (mm) | Wheel (mm) | Offset (mm) | Plate (mm) | Hole centre (mm) | Bolt hole (mm) | Load (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 22075NP | 22075NPF | 22075NPB | 107 | 75x32 | 32 | 92x63 | 75x47 | 8x11 | 70 |
| 22100NP | 22100NPF | 22100NPB | 130 | 100x32 | 33 | 92x63 | 75x47 | 8x11 | 80 |
| 22125 NP | 22125NPF | 22125NPB | 157 | 125x31 | 34 | 92x63 | 75x47 | 8x11 | 110 |
