22075NP · Swivel / Fixed / Brake
PVC, PP & Grey TPR Caster
Light & furniture casters75–125 mm · up to 110 kg
Brake / lockFY / ML Series · 25050Z
PP Nylon & PVC Caster
PP nylon / PVC caster (double ball bearing).
PP nylon / PVCDouble ball bearingLight & furniture casters
Type
Wheel size (mm)
- Load / caster
- 60 kg
- Overall height
- 74 mm
- Wheel
- 50x25
Message: “Hi Star Brand, I'm interested in 25050Z, 50x25 mm. Please share price and availability.”
- Bulk and dealer orders welcome
- We reply the same working day.
DWG · 25050Z · not to scale
Technical drawing
Key dimensions for the selected size. Full figures are in the table below.
Specifications
As printed in the Star Brand catalogue, page 14. Tap a row to select that size.
| Swivel code | Fixed code | Brake code | Height (mm) | Wheel (mm) | Offset (mm) | Plate (mm) | Hole centre (mm) | Bolt hole (mm) | Load (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 25040Z | 25040ZF | 25040ZB | 60 | 45x21 | 16 | 60x43 | 48x31 | 6 | 50 |
| 25050Z | 25050ZF | 25050ZB | 74 | 50x25 | 21 | 72x52 | 56x35 | 8x11 | 60 |
| 25065Z | 25065ZF | 25065ZB | 94 | 64x31 | 25 | 94x63 | 75x47 | 8x11 | 70 |
